Product Description
Walther Electric 410405 Pin and Sleeve Receptacle 20A 4 Wire 600 VAC 5Hr IP44 Splashproof (Black) is interchangeable with other IEC 60309 industrial grade 420R5 electrical receptacles.
- RETAINING DEVICE – Prevents unintentional withdrawal when male and female devices are connected
- SHROUDED PINS – Nickel-plated solid-brass pins offer corrosion protection and excellent conductivity
- FIRST MAKE/LAST BREAK (FMLB) - Preventing making or breaking the circuit under load
- COLOR-CODED – All IEC 60309 Pin & Sleeve Devices are color-coded by voltage for easy Identification and safe pairing
- HIGH IMPACT THERMOPLASTIC – Heavy-duty insulated housings are resistant to corrosion and abrasions
NOTE: Interchangeable with industry part number for application. If attempting to mate with a non-walther part, please speak with a member of our engineering department.
Product Videos
Custom Field
CEE typ DEVICE TYPE IEC 60309 Receptacle (Panel Socket)
AMPS (North America) 20A
ENVIRONMENTAL RATING IP44 Splashproof
POLES & WIRES 4 Wires = 3 Poles +Earth Ground (3P+G)
CLOCK POSITION 05 Hour
VOLTAGE (North America) 3ø 600 VAC
COLOR Black
ANGLE OF DEVICE Straight
CERTIFICATIONS (North America) UL Listed & CSA Certified
PAIRS WITH 212405 Plug and more
