Product Description
Walther Electric 269405 Pin and Sleeve Plug 60A 4 Wire 600 VAC 5Hr IP67 Watertight (Red) is interchangeable with other IEC 60309 industrial grade 460P5W electrical plug.
- RETAINING DEVICE – Prevents unintentional withdrawal when male and female devices are connected
- SHROUDED PINS – Nickel-plated solid-brass pins offer corrosion protection and excellent conductivity
- FIRST MAKE/LAST BREAK (FMLB) - Preventing making or breaking the circuit under load
- COLOR-CODED – All IEC 60309 Pin & Sleeve Devices are color-coded by voltage for easy Identification and safe pairing
- HIGH IMPACT THERMOPLASTIC – Heavy-duty insulated housings are resistant to corrosion and abrasions
NOTE: Interchangeable with industry part number for application. If attempting to mate with a non-walther part, please speak with a member of our engineering department.
Product Videos
Custom Field
CEE typ DEVICE TYPE IEC 60309 Plug
AMPS IP67 Watertight
POLES & WIRES 4 Wires = 3 Poles +Earth Ground (3P+G)
CLOCK POSITION 05 Hour
VOLTAGE 3ø 600 VAC
COLOR Black
CABLE GLAND Trumpet/Bell Gland
CERTIFICATIONS (North America) UL Listed & CSA Certified
PAIRS WITH 369405 Coupler and more
